SCM Hoge Afbuiging Trillingsdemper
Details
SCM Dempers bieden een grote flexibiliteit in zowel de horizontale als verticale richting voor ventialtoren, waaiers en roterende pompen.
Specifaties:
- Hoogelastische machinevoeten
- oogwaardig natuurrubber
- Verkrijgbaar met roestvrij staal of standaard staal delen.
|
Toepassing:
- Ventilatoren
- airconditioningunits,
- koelcompressoren,
- Waaiers en roterende pompen
- Ondersteuning leidingwerk
|
|
45 IRHD |
60 IRHD |
| Artiekel No |
MAX Kg's |
MAX mm |
MAX Kg's |
MAX mm |
| SCM6420 |
3.5 |
3 |
9 |
3.5 |
| SCM 8525 |
20 |
4 |
40 |
4.5 |
| SCM 8525M10 |
20 |
4 |
40 |
4.5 |
| SCM 10027 |
30 |
4.5 |
55 |
5.0 |
| SCM 10027/1 |
30 |
4.5 |
55 |
5.0 |
| SCM 11435 |
40 |
6.0 |
65 |
8.5 |
| SCM 13640 |
70 |
8.5 |
130 |
11 |
| SCM 15063 |
280 |
- |
500 |
- |
| SCM 15145 |
130 |
10.0 |
220 |
10.0 |
| SCM 20085 |
380 |
18 |
750 |
18 |
| SCM 310160 |
1400 |
45 |
2500 |
50 |
Extra informatie
| Hardheid (Shore A) |
N/B |
| Materiaal |
NR |
| Binnen Diameter (mm) |
Nee |
| Ovale Gat (mm) |
Nee |
| Breedte (mm) |
Nee |
| Binnen Breedte (mm) |
Nee |
| Hoogte (mm) |
Nee |
| Dikte (mm) |
Nee |
| Maximale Lading in Compressie (Kg) |
Nee |
| Maximale Afbuiging (mm) |
Nee |
*De afmetingen kunnen enigszins variëren en zijn tot toleranties gemaakt.
