Polymax VIBTEC - Cork Rubber Tiles

Schrijf de eerste review van dit product

Snel overzicht

Helps reduce noise and vibration, while being able to work in temperatures between -20 and + 120ºC. Ideal for installation of low and high frequency of machines, such as washing machines.

LEAD TIME 3-5 DAYS

€ 23,01 24.9
€ 45,55 49.3
€ 90,62 98
€ 144,02 155.8
€ 186,42 201.7
€ 298,46 322.9
€ 350,80 379.5
Article No. Length (mm) Width (mm) Thickness (mm) Prijs Aantal
1+ 5+ 10+
1055219 1000.001000.001.50
€ 30,07
€ 26,14
€ 23,01
1055220 1000.001000.003.00
€ 59,53
€ 51,77
€ 45,55
1055221 1000.001000.006.00
€ 118,42
€ 102,98
€ 90,62
1055222 1000.001000.0010.00
€ 188,19
€ 163,64
€ 144,02
1055223 1000.001000.0013.00
€ 243,60
€ 211,83
€ 186,42
1055224 1000.001000.0020.00
€ 390,02
€ 339,15
€ 298,46
1055225 1000.001000.0025.00
€ 458,45
€ 398,63
€ 350,80

Details

Polymax VIBTEC is a technical grade cork sheet made of a highly compressible material bounded by Nitrile rubber, in a rusty red colour. VIBTEC is suitable for low or medium bolt pressure with good flexibility and resilience, it also offers a wide temperature range and stress resistance. It is great for noise and vibration control and has excellent oil and fuel resistance. Easy installation as it avoids anchor bolts and will lead to no floor damage.


VIBTEC is a more expensive cork, compared to the Polymax ABACUS which is the more economical cork we sell. VIBTEC compared to ABACUS has a lower compressible medium density cork and rubber material for noise and vibration control. VIBTEC’s binder is Nitrile and as a result the volume doesn’t change as much as ABACUS, which has a binder of Neoprene, when immersed in the different types of oils and fuels. This means that VIBTEC has excellent oil and fuel resistance compared to ABACUS.


Applications:
• Lifts
• Conveyors
• Generators
• Vacuum pumps
• Workshops
• Drills
• Power pressers
• Washing Machines

Extra informatie

Colour Rood
Materiaal Nitrile
Rol lengte (m) Nee
Breedte (mm) Nee
Dikte (mm) Nee
Tolerancie (±mm) Nee
Sell by the metre Nee
Hardheid (Shore A) 65
Maximale Temperatuur (°C) 120.00
Minimaal Temperatuur (°C) -20.00
Density (kg/m³) Nee
Density (g/cm³) Nee
Treksterkte (MPa) 23.50
Rek bij breuk % Nee
Slijtage mm3 (DIN 53516) Nee
Veilige Spanning (V) Nee
Voltage tested tot en met (V) Nee
Aantal vezelversterkende lagen Nee
Flooring Features Nee
Blijvende indrukking % 50.00
Blijvende indrukking proef methode Nee
*Dimensions can vary, they are typical only.
